IC1318 in Cygnus
A two panel mosaic at 0.75 a-s/px comprising a very small portion of the Gamma Cygni Nebula. The field is centered 2 degrees northwest of Sadr.
Imaged from Nova Scotia, Summer 2022
HaRGB Combination
| Data | |
|---|---|
| Altitude at culmination 89° | |
| Minimum Airmass Value (sec z) 1.0 | |
| Taking Camera SBIG STL-11002XM | Nova Scotia Summer 2022, skies ~mag 6.4 -sensor @-20C |
| Imaging OTA | AGO 14.5" iDK |
| Equivalent focal length and ratio | 2465mm @ f/6.7 |
| Mount | Astro-Physics 1600GTO |
| Guiding | PHD2/ONAG/Lodestar X-2 |
| HaRGB Two panel mosaic. Total Integration Time 26hrs 10mins | Ha22x30m, R30x10m, G31x10, B30x10m, Astrodon Gen 2 I series RGB filters and 5nm Ha filter. All Binned 1X1 | Acquisition | Main Sequence Software-Sequence Generator Pro | Calibration and Stacking | Darks, Flats and Bias - Stacked and calibrated with PixInsight |
| Reprocessed Jan 2023 | PixInsight, Affinity Photo v2.04 and Bob Franke's CCDBand-Aid |
Ha Only
Annotated Frame
